HologramLib is a protocol-layer display library for Bedrock servers (LeviLamina / BDS): one API that pushes shapes, holograms, items, entities and menus straight to the client — no real entities spawned, nothing written to the save, no server-side world state touched.

The same capabilities are reachable two ways: C++ plugins (frozen pure-virtual interfaces) and LSE scripts (ll.import).

This is a prerequisite library, not a feature plugin: it provides rendering primitives, protocol wrappers and timing notifications only. Commands, forms, permissions, placeholders and persistence belong to the consumer.

Changelog

The complete changelog lives in the changelog.

Full documentation

HologramLib docs site

How to write

C++ plugin

#include "hologramlib/HologramLib.h"

// Gate the capability at compile time; handshake at runtime in case an older build is installed
static_assert(HOLOGLIB_API_VERSION >= 0x011B00, "requires 1.21.0 (ITradeMenu)");

auto& lib = hologramlib::IHologramLib::getInstance();

// Holographic text: one text shape per block, lines joined with \n, inline colours via § codes
auto holo = lib.holograms().create(0, 70, 0);
lib.holograms().addLine(holo, "§eWelcome to spawn");
lib.holograms().addLine(holo, "Online: {online}");         // {var} resolves per viewer
lib.holograms().setDepthTest(holo, true);                  // true = occluded by blocks (default is see-through)
lib.holograms().draw(holo);

// Shapes: line + colour + lifetime
auto line = lib.shapes().createLine(0, 64, 0, 10, 64, 10);
lib.shapes().setColor(line, 1.0f, 0.2f, 0.2f, 1.0f);
lib.shapes().draw(line);

// Virtual container: a list UI any input device can click (a click is an item pickup)
hologramlib::ContainerMenuSpec menu;
menu.title = "§8Quest list";
menu.rows  = 3;                                            // 3 = 27 slots; 6 = 54 slots
menu.items.resize(27);
menu.items[0].type = "minecraft:diamond_sword";
menu.items[0].name = "§bTrial";
auto menuId = lib.containerMenus().open("Steve", menu);
lib.containerMenus().setItem(menuId, 0, {"minecraft:barrier", 1, 0, "§cDone", {}});

xmake integration:

add_includedirs("../HologramLib/include")
add_linkdirs("../HologramLib/build/windows/x64/release")
add_links("HologramLib")

LSE script

The standard LSE interfaces (mc, ll, logger, events, NBT, forms, databases …) are covered by the LSE docs; this section only covers HologramLib's own namespace.

// One namespace, "HologramLib", with 16 domain prefixes
const holoCreate      = ll.import("HologramLib", "holoCreate");
const containerOpen   = ll.import("HologramLib", "containerOpen");
const sensingIsTouch  = ll.import("HologramLib", "sensingIsTouch");

// Route by client device: touch players get the virtual container (clicks always send a packet)
if (sensingIsTouch("Steve")) {
    const id = containerOpen("Steve", "§8Quest list", 3);
    // Drain clicks from a guard/timer loop (reading empties the queue)
    for (const line of ll.import("HologramLib", "containerPollClicks")()) {
        // "player=Steve menuId=1 slot=0 closed=0"
    }
}

Installation

1. Stop the server.
2. Extract the release archive HologramLib.zip and drop the resulting HologramLib folder into the server's plugins/, giving plugins/HologramLib/ (containing HologramLib.dll and manifest.json).
3. Start the server. Load order does not matter: the library checks for the LSE compatibility layer during enable() and retries on ServerStarted.

Consumers only need getInstance() in enable(); there is no declared dependency to add.

Release builds are completely silent: all diagnostic logging is disabled at compile time and the log strings never enter the binary. To debug, temporarily enable it with xmake f --holo_diag=y && xmake build -y, and reset it (--holo_diag=n) before shipping.

Versions

The full mapping, the encoding rule, and the reasons behind the two documented API shrinks are in the version & ABI matrix.

License

MIT — see LICENSE.

The holographic-text "dynamic lines" feature (the FloatingTextLine content pool, rotation interval, per-line variable toggle, interval-modulo rotation, 0.5 s throttled refresh with per-player resend, and content deduplication) is derived from Phantom (a LeviLamina Bedrock hologram plugin, GNU Lesser General Public License v3.0).

As required by LGPL-3.0, the origin is stated here: that derived part and its derivative works are distributed under LGPL-3.0, copyright held by the Phantom contributors (GroupMountain); the rest of the library remains MIT. Distributions that include that part must also satisfy LGPL-3.0: keep the copyright and licence notices, provide the corresponding source (locations: the file header of src/FloatingTextManager.h, the comments above the relevant functions in src/FloatingTextManager.cpp, this README and docs/versions/api-version-matrix.md), and keep that part replaceable / independently rebuildable.
